JST XHB SMD 2.54 Mm Pitch 2-Pin/3-Pin/4-Pin JST Connector IC Male Plugs, Female Sockets Housing And T-Shaped Crimp Terminal Kit. 75 Sets/375 Pieces Wire-to-Board Adapter Cable Assembly. Brand

Currently, failures due to defective IC sockets and plug connectors account for more than 37% of all equipment failures. connector IC sockets and plugs play the role of conducting electricity and connecting signals in electronic equipment. Due to their stronger and more reliable characteristics, they are used in various devices. APPLICATION - Industrial Production - Electronic Integration - Computer Application - Medical Equipment SPECIFICATION - Model: JST XHB 2 pin / 3 pin / 4 pin - Pitch: 2.54 mm (0.1 inch); - Current Rating: 3A AC/DC (AWG #20); - Voltage Rating: 250V AC/DC; - Temperature Range: -25 Degree Celsius to +85 Degree Celsius(including temperature rise in applying electrical current); - Contact Resistance: Initial value / 10 Milliohm max; After Environmental Testing / 20 Milliohm max; - Insulation Resistance: 1000 Megaohm above; - Withstanding Voltage: 1000V AC/one minute; - Applicable Wire: AWG#20 to AWG#28 - Applicable PCB thickness: 1.6mm. (0.063 inches) DISTRIBUTION LIST 1 * JST XHB 2.54 mm Pitch 2-Pin/3-Pin/4-Pin Wiring Connecting IC Male Plugs, Female Sockets Housing and T-shaped Crimp Terminal Kit. (90 sets / 450 pieces) JST XHB 2.54 mm pitch wire connection terminal IC male plug, 30 Pieces each for 2-pin, 3-pin, 4-pin, 90 pieces in total. 270 Pieces 2.54 mm pitch JST XHB T-shaped Crimp Terminal. JST XHB 2.54 mm pitch wire connection terminal IC female sockets housing, 30 pieces each for 2-pin, 3-pin, 4-pin, 90 pieces in total. JST 2.54 mm (0.1 inch) B2B / B3B / B4B-XHB-K-S shrouded socket with through hole. 450 pieces / 90 sets JST XHB 2.54 mm pitch 2 pin / 3 pin / 4 pin wiring connecting IC male plugs, female sockets housing and T-shaped crimp terminal kit. PP plastic double sided comXArtment XArts box - 10 comXArtments XAckage.
